flip top cap mould maker

Flip top cap mould is very important to make the flip top cap mould well to get qualified flip top caps, is required much for different kinds of flip top caps for shampoo bottle, oil bottle, tomato sauce bottle and so on.

For a good flip top cap mould, it means we could produce good flip top caps with same quality,and the flip top cap mould could run fully automatically with high production efficiency.

For a good flip top cap, when push the flip top to close, there should have sound, when we open the flip top cap to a certain location, it could open fast by itself, this required the butterfly design and also suitable raw material for the flip top cap, when the flip top cap is closed with the bottle, it must have water proof function.

After we know the requirement for a good flip top cap, we could make the flip top cap mould accordingly.

First, flip top cap mold design, the important is for injection gate location choosing, cooling system design and ejection structure design. After the mould design finished, our engineers will have a meeting to discuss about the mould movement to improve the mould structure.

Second, flip top cap mold tooling, we use stainless steel material for the core and cavity,which required twice tooling. The tooling accuracy is highly required, both for the matching and butterfly function. especially for the butterfly thickness, it will decide the flip top cap closing & opening stretch.

Third, flip top cap mold testing and production. The experience for machine setting is very important for this kind of mould, include the injection speed and pressure setting. Olny when we consider for all the factors, we could get a high quality flip top cap mould.

flip top cap mould, flip top cap mold, cap mould

Mould steel: S136, H13 etc.
Mould base: S45C, LKM ect.
Cavity: multi
Runner: Hot runner / cold runner
Mould life: More than 1,500,000 shots
Design software: UG, PROE, CADetc.
Plastic material: PP etc.
Delivery time: 45-55 days
Specification: According to client’s requirements
Packing: wooden case
Shipment: FOB Ningbo / Shanghai
